China AC Contactor CJ40 ZNFO Traditional Series - 690V, 1000A, Reliable Suppliers and Factory Solutions
Type and meaning
Type and meaning
The auxiliary code is composed of 5 parts, which are selected in the following order as needed:
-
In the first part: “y” means general type, “N” (can be omitted) means reversible type;
-
In the second part: 1 digit is used to indicate the number of poles of the main circuit: 3 and 4 respectively indicate 3 and 4 poles, and 3 can be omitted;
-
In the third part: 2 digits are used to indicate the highest rated working voltage, "06" (which can be omitted) indicates 690V, "11" indicates 1140V;
-
The fourth part indicates the rated control power supply voltage, with letters "Ac" indicating alternating current 50 Hz and "Dc" indicating direct current. The value of the rated control power supply voltage is behind the letters, but “AC380” can be omitted;
-
In the fifth part: the letter "□" and two digits are used together to indicate the type and number of auxiliary contacts, of which the first digit indicates the number of pairs of normally open auxiliary contacts and the second digit indicates the number of pairs of normally closed auxiliary contacts, but “□42” can be omitted.
Note: This item includes two parts, i.e., the number of main contacts and the number of auxiliary contact, which are indicated by number respectively, as shown in the diagram below. ( -□□-□□ ) indicates: - number of normally open main contacts, number of normally closed main contacts - number of normally open auxiliary contacts, number of normally closed auxiliary contacts.
Normal working conditions and installation conditions
-
The altitude of the installation site should not exceed 2000m;
-
The ambient air temperature should not be higher than +40℃ and not be lower than -5℃;
-
When the highest temperature is +40℃, the relative humidity of the air on the installation site should not be higher than 50%; A higher relative humidity is allowed at a lower temperature; In the wettest month, the monthly average minimum temperature should not exceed +20℃, and the average maximum relative humidity should not exceed 90%. Measures should be taken for condensation on the product due to temperature change;
-
The inclination between the installation surface and the vertical plane should not exceed ±5°.
-
Pollution level: level 3;
-
The product should be installed in a place without obvious shaking, impact and vibration.
Structural features of the product
CJ40-63~1000 AC contactor adopts the structure of oven type, normal installation, direct acting and double breakpoints. The auxiliary contacts are installed on both sides of the main contact as independent components, which are electrically separated; The iron core is a U-shaped structure with the permanent air gap. The base is made of aluminum alloy die-casting (for CJ40-630A and above), which is installed by screws: But. The base of CJ40-63~125 is made of unsaturated polyester glass fiber reinforced molding compound, which may be installed by screws or by “TH75” guide rail. With the advantages of high breaking capacity and high reliability, etc., the arc extinguishing chamber is made of arc resistant plastic and iron grid.
Outline and installation dimensions
Outline and installation dimensions of CJ40-63~1000 AC contactor
| Product type | Outline dimensions (Max) |
Installation dimensions |
Installation rail |
Installation area F min |
|||||
A |
B |
C |
a |
b |
φ |
380V |
660v |
||
| CJ40-63-125 | 116 |
143 |
154 |
100 |
90 |
5.8 |
Th75 |
20 |
40 |
| CJ40-160-200 | 146 |
186 |
184 |
130 |
130 |
9 |
- |
30 |
40 |
| CJ40-250 | 40 |
60 |
|||||||
| CJ40-315-400 | 190 |
235 |
230 |
160 |
150 |
9 |
40 |
60 |
|
| CJ40-500 | 50 |
70 |
|||||||
| CJ40-630-1250 | 245 |
345 |
288 |
210 |
180 |
11 |
0 |
0 |
|
| CJ40-63/4~125/4 | 143 |
143 |
154 |
128 |
90 |
5.8 |
Th75 |
20 |
40 |
| CJ40-63/4~200/4 | 187 |
186 |
184 |
170 |
130 |
9 |
- |
30 |
40 |
| CJ40-250-4 | 40 |
60 |
|||||||
| CJ40-315/4~400/4 | 236 |
235 |
230 |
216 |
150 |
9 |
40 |
60 |
|
| CJ40-500/4 | 50 |
70 |
|||||||
Main parameters and technical performance
| Type and specification | Frame code |
u A |
|
th A |
leA under intermittent periodic work |
ing system AC-4 |
Pe kW under AC-3 |
leA under different intermittent working systems |
||
AC-1 |
AC-2 |
AC-3 |
||||||||
| C40-63 | 125 |
220 |
80 |
80 |
63 |
63 |
63 |
18.5 |
80 |
|
380 |
30 |
|||||||||
| CJ40-80 | 660 |
|||||||||
220 |
80 |
80 |
80 |
|||||||
380 |
||||||||||
| C140-100 | 660 |
63 |
63 |
63 |
55 |
|||||
220 |
125 |
125 |
100 |
100 |
100 |
30 |
125 |
|||
380 |
||||||||||
| CJ40-125 | 660 |
80 |
80 |
80 |
||||||
220 |
125 |
125 |
125 |
|||||||
380 |
10 |
|||||||||
660 |
80 |
80 |
80 |
|||||||
| CJ40-160 | 250 |
690 |
220 |
250 |
250 |
160 |
160 |
160 |
45 |
250 |
| CJ40-200 | 380 |
75 |
||||||||
660 |
125 |
125 |
125 |
110 |
||||||
220 |
200 |
200 |
200 |
55 |
||||||
| C40-250 | 380 |
90 |
||||||||
660 |
125 |
125 |
125 |
110 |
||||||
220 |
250 |
250 |
250 |
75 |
||||||
380 |
225 |
132 |
||||||||
660 |
125 |
125 |
125 |
110 |
||||||
| CJ40-315 | 500 |
690 |
220 |
500 |
500 |
315 |
315 |
315 |
90 |
500 |
| CJ40-400 | 380 |
250 |
160 |
|||||||
660 |
300 |
|||||||||
| CJ40-500 | 220 |
400 |
400 |
400 |
110 |
|||||
380 |
315 |
220 |
||||||||
660 |
315 |
315 |
300 |
|||||||
220 |
500 |
500 |
500 |
150 |
||||||
380 |
400 |
280 |
||||||||
660 |
315 |
315 |
315 |
300 |
||||||
| CJ40-630 | 1000 |
690 |
220 |
800 |
630 |
630 |
630 |
630 |
200 |
630 |
| CJ40-800 | 380 |
500 |
335 |
|||||||
| C140-1000 | 660 |
500 |
500 |
500 |
475 |
|||||
220 |
800 |
800 |
800 |
800 |
250 |
800 |
||||
380 |
630 |
450 |
||||||||
| CJ40-1250 | 1250 |
660 |
500 |
500 |
500 |
475 |
||||
220 |
1000 |
1000 |
1000 |
1000 |
1000 |
360 |
1000 |
|||
380 |
550 |
|||||||||
660 |
630 |
630 |
500 |
570 |
||||||
220 |
1250 |
1250 |
1250 |
1250 |
1250 |
375 |
1250 |
|||
380 |
600 |
|||||||||
660 |
800 |
800 |
600 |
630 |
||||||
| C40-125/11 | 1250 |
1140 |
1140 |
125 |
125 |
40 |
40 |
40 |
55 |
125 |
| C140-250/11 | 250 |
1140 |
250 |
250 |
80 |
80 |
80 |
110 |
250 |
|
| C140-500/11 | 500 |
1140 |
500 |
500 |
160 |
160 |
160 |
220 |
500 |
|
| CJ40-1000/11 | 1000 |
1140 |
1000 |
1000 |
400 |
600 |
1000 |
|||
Frequently Asked Questions (FAQ)
Q
What does the "y" and "N" in the auxiliary code represent?
"y" represents the general type, while "N" (which can be omitted) represents the reversible type.
Q
What are the installation altitude and temperature limits for the CJ40 series AC contactor?
The installation site altitude should not exceed 2000m. The ambient air temperature must remain between -5℃ and +40℃ for normal operation.
Q
What are the relative humidity requirements for the installation site?
At a maximum temperature of +40℃, relative humidity should not exceed 50%. Higher humidity is allowed at lower temperatures, but the monthly average minimum temperature of the wettest month should not exceed +20℃ with a maximum relative humidity of 90%.
Q
What structural features does the CJ40-63~1000 AC contactor feature?
It features an oven-type, direct-acting, and double-breakpoint structure. The auxiliary contacts are independent, electrically separated components installed on both sides of the main contact.
Q
How is the base of the CJ40 series contactor constructed and installed?
For CJ40-630A and above, the base is made of screw-installed aluminum alloy die-casting. For CJ40-63~125, the base is made of unsaturated polyester glass fiber reinforced molding compound and can be installed via screws or a "TH75" guide rail.
Q
What is the required pollution level and vibration resistance for the installation environment?
The contactor is rated for Pollution Level 3 and must be installed in environments free from obvious shaking, impact, and vibration.
